CPU Specifications Total Cores 6 # of Performance-cores 6 # of Efficient cores 0 Total Threads 12 Max Turbo Frequency 4.40 GHz Performance-core Max Turbo Frequency 4.40 GHz Performance-core Base Frequency 2.50 GHz Cache18 MB Intel® Smart Cache Total L2 Cache 7.5 MB Processor Base Power 65 W Maximum Turbo Power 117 W |
| • |
Supplemental Information Embedded Options Available Yes Datasheet View now |
| • |
Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s Max # of Memory Channels 2 Max Memory Bandwidth 76.8 GB/s |
| • |
Processor Graphics Processor Graphics ‡Intel® UHD Graphics 730 Graphics Base Frequency 300 MHz Graphics Max Dynamic Frequency 1.45 GHz Graphics Output eDP 1.4b, DP 1.4a, HDMI 2.1 Execution Units 24 Max Resolution (HDMI) ‡4096 x 2160 @ 60Hz Max Resolution (DP)‡ 7680 x 4320 @ 60Hz Max Resolution (eDP - Integrated Flat Panel) ‡5120 x 3200 @ 120Hz DirectX* Support 12 OpenGL* Support 4.5 Multi-Format Codec Engines 1 Intel® Quick Sync Video Yes Intel® Clear Video HD Technology Yes # of Displays Supported ‡4 Device ID 0x4692 / 0x4682 OpenCL* Support 2.1 |
| • |
Expansion Options Direct Media Interface (DMI) Revision 4.0 Max # of DMI Lanes 8 Scalability 1S Only PCI Express Revision 5.0 and 4.0 PCI Express Configurations ‡Up to 1x16+4, 2x8+4 Max # of PCI Express Lanes 20 |
| • |
Package Specifications Sockets Supported FCLGA1700 Max CPU Configuration 1 Thermal Solution Specification PCG 2020C T-JUNCTION 100°C Package Size 45.0 mm x 37.5 mm |
| • |
Advanced Technologies Intel® Gaussian & Neural Accelerator 3.0 Intel® Thread Director No Intel® Deep Learning Boost (Intel® DL Boost) Yes Intel® Optane™ Memory Supported ‡Yes Intel® Speed Shift Technology Yes Intel® Turbo Boost Max Technology 3.0 ‡No Intel® Turbo Boost Technology ‡2.0 Intel® Hyper-Threading Technology ‡Yes Intel® 64 ‡Yes Instruction Set 64-bit Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 The idle States Yes Enhanced Intel SpeedStep® Technology Yes Thermal Monitoring Technologies Yes Intel® Volume Management Device (VMD) Yes |
| • |
Security & Reliability Intel® Threat Detection Technology (TDT) Yes Intel® Standard Manageability (ISM) ‡Yes Intel® AES New Instructions Yes Secure Key Yes Intel® OS Guard Yes Execute Disable Bit ‡Yes Intel® Boot Guard Yes Mode-based Execute Control (MBEC) Yes Intel® Control-Flow Enforcement Technology Yes Intel® Virtualization Technology (VT-x) ‡Yes Intel® Virtualization Technology for Directed I/O (VT-d) ‡Yes Intel® VT-x with Extended Page Tables (EPT) ‡Yes |
