HIKVISION 16CH TURBO HD 4MP DVR IDS-7216HQHI-K1/4S ACUSENS
Add to Wishlist- H.265(K-series) and H.264 video compression
- High Definition real-time recording
- Support Turbo HD video input
- Easy smart search for motion event during playback
- HDMI output at up to 4K resolution
- Live view from smart device or Internet
- Two-way audio
- Multi-channel synchronous playback
| • | Recording Encoding Resolution Main stream: When 1080p lite mode not enabled: For 4 MP stream access: 4 MP lite@15 fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps For 1080p stream access: 1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) When 1080p Lite mode enabled: 4 MP lite/3 MP@15 fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N) Video Bit Rate32 Kbps to 6 Mbps Dual Stream Support Stream Type Video, Video & Audio Audio CompressionG.711u Audio Bit Rate64 Kbps |
|---|---|
| • | Video And Audio IP Video Input 2-ch (up to 18-ch) IP enhanced mode on: 8-ch (up to 24-ch), each up to 4 Mbps AHD Input4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps HDCVI Input4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps CVBS Input PAL/NTSC HDMI/VGA Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, HDMI/VGA simultaneous output Audio Input1-ch, RCA (2.0 Vp-p, 1 K?) Audio Output1-ch, RCA (Linear, 1 K?) Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 K?) (using the first audio input) Synchronous Playback16-ch HDTVI Input 3 MP, 1080p@30 fps, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps *: The 3 MP signal input is only available for channel 1 of iDS-7204HQHI-K1/2S(B), for channel 1/2 of iDS-7208HQHI-K1/4S(B), and for channel 1/2/3/4 of iDS-7216HQHI-K1/4S(B). CVBS Output1-ch, BNC (1.0 Vp-p, 75 ?),,resolution: PAL: 704 × 576, NTSC: 704 × 480, |
| • | Network Remote Connections128 Network Interface1,,RJ45 10M/100M/1000M ,self-adaptive ,Ethernet interface, |
| • | Auxiliary Interface SATA1 SATA interfaces Capacity Up to 10 TB capacity for each disk Alarm In/Out N/A USB Interface2 × USB 2.0 |
| • | General Power Supply12 VDC Working Temperature-10 °C to +55 °C (+14 °F to +131 °F) Working Humidity10% to 90% Weights (Without HDD)? 2 kg (4.4 lb) Consumption(Without HDD)? 18 W Dimensions(W × D × H)315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) |
