TPS51461RGER IC
Product Title: TPS51461RGER (Marking: TPS51461 / TI IAI / A2J5) 4.5V to 13.8V Input, 6A Synchronous Step-Down Converter IC (VQFN-24)
Product Specifications:
- Part Number / Marking: TPS51461RGER (Top Marking Code: TPS51461 / TI IAI / A2J5)
- Device Type: Synchronous Step-Down (Buck) Converter with Integrated Power MOSFETs
- Package / Case: VQFN-24 / RGE-24 (24-Pin Very Thin Quad Flat No-Lead, 4x4mm with Exposed Thermal Pad)
- Input Voltage Range ($V_{IN}$): $4.5\text{V to }13.8\text{V DC}$
- Bias Supply Voltage ($V_{CC}$): $4.5\text{V to }5.5\text{V DC}$
- Continuous Output Current ($I_{OUT}$): Up to $6\text{A}$
- Adjustable Output Voltage Range ($V_{OUT}$): $0.7\text{V to }2.0\text{V}$ (Internal $0.7\text{V}$ Precision Reference)
- Control Architecture: D-CAP+™ Mode Control for Fast Dynamic Transient Response
- Switching Frequency: Selectable $700\text{ kHz}$ or $1\text{ MHz}$ Frequency Operation
- Operating Temperature Range:$-40^\circ\text{C}\text{ to }+85^\circ\text{C}$
Short Description: Texas Instruments TPS51461RGER (top marking: TPS51461) integrated 6A synchronous step-down buck converter IC in a 24-pin VQFN package. Features internal power MOSFETs and TI’s proprietary D-CAP+™ control mode for ultra-fast transient response and stable operation with low-ESR ceramic capacitors. Widely used on laptop motherboards, graphics cards, and compact system logic boards to drive high-current low-voltage rails such as CPU VCCSA, GPU core, and system RAM controllers. Essential replacement chip for resolving short-circuit power trips, missing low-voltage power rails, GPU/CPU power failures, and motherboard power-on issues.
IC උපාංග සහ Parts නැවත බර ගනු නොලැබේ | හුවමාරුවක් නැත | වගකීමක් නැත | මුදල් ආපසු ගෙවීමක් නැත කරුණාකර ඔබගේ අංකය පරීක්ෂා කර එය ඔබගේ පවතින නිෂ්පාදනය සමඟ ගලපන්න. ඔබ මෙම නිෂ්පාදනය අපගේ වෙබ් අඩවියෙන් මිලදී ගෙන එය මවු පුවරුවේ සවි කළ විට, එය ඔබේම අවදානම මත පවතිනු ඇත. කිසිදු දෝෂයකට අප වග කියනු නොලැබේ
